Packing scope
- Facial tissue, lotion tissue, Non-woven tissue, napkin
- Mini package 20mm packing height can be done
| Packing scope | Facial tissue, lotion tissue, non-woven tissue, napkin |
|
Finished Product Packing Size(mm) |
L(105-200)* W(85-105)*H(20-70) (Other sizes can be ordered) |
|
Packing material |
CPP, PE,ect. double sides heat sealing film |
|
Packing speed |
25-95packages/ min |
| Opening perforation unit | One set |
| Code printer | One set |
| Antistatic | Static eliminator |
|
Lubrication |
Automatic oil-filling lubrication system |
| Control system | PLC, inverter and servo motor |
| Mini package | 20mm packing height can be done |
| Wrapping type | Rotating turn-table type |
| Safe cover | Machine overall safe cover |
| Total power | 6.8Kw |
| Machine dimension (mm) | L 3800 * W 4250 * H1800 |
| Power supply | 380V 50Hz (3-phases, 4wires) (other voltage to be ordered) |
| Machine weight | About 3000Kg |
| Tissue alignment conveyor | Before wrapping |
|
Pneumatic System |
0.5-0.6 Mpa ( customer supplied) |
Rotating turn-table wrapping
- Various packing specifications can be shifted quickly.
Opening perforation ( two types for you to choose from)
- Easy open perforation
- Straight line perforation
Different models of hight speed optional
- High speed 110bags/min, 160bags/min, 180bags/min for you to choose from
Various packing sizes can be ordered
- Mini package: 20mm packaging hight can be ordered
- Maximum package hight 120mm can be ordered
Production date and batch number printer
